Absolute solution for all kinds of water sources with very high dirt loads.
Automatic self-cleaning KFH-WBVV-MR filters are ideal and provide permanent solution for sea water and surface water filtration with their rust-proof construction.
| Body Material | Max. Operating Temperature | Back-Flush Water Consumption |
|---|---|---|
| AISI 304L, AISI 316L | 60°C / 90°C | 200 – 400 l / back-flush |
| Screen Material | Headloss at Max. Flow Rate | Fine Screen Range |
| AISI 316L | 0.2 bar | 10 – 3000 micron |
| Max. Operating Pressure | Back-Flush Time | Control System |
| PN10 / PN16 | 40 – 60 s | Electric |
| Min. Inlet Pressure Required During Back-Flush | rpm of Cleaning Mechanism | |
| 2 bar | Adjustable |
For different pressure and material requirements, please contact us.
Suitable applications
- Hydroelectric plant water treatment
- Aquafarming
- Reverse osmosis, Sea water
- Surface water treatment
- Pulp & paper industry
